Technical Specifications
EBIKE |
Motor All New Specialized 3.1 Motor, 101Nm torque, 666W power Battery 840wh battery UI/Remote All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized app Charger Specialized 4amp charger
|
|---|---|
FRAMESET |
Frame All new Levo 4 frame, FACT 11m carbon chassis and rear-end, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, w/ SWAT storage, 150mm of travel, side entry battery, fork travel up to 180mm Seat Binder Alloy, 38.6mm |
SUSPENSION |
Rear Shock FOX FLOAT X Performance Elite with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment Fork FOX 38 Performance Elite series, 29", GRIP X2 damper,15x110mm axle, 44mm offset, 160mm of travel |
BRAKES |
Front Brake SRAM Maven Silver, 4-piston caliper, hydraulic disc, 220mm Rotor Rear Brake SRAM Maven Silver, 4-piston caliper, hydraulic disc, 200mm rotor |
DRIVETRAIN |
Shift Levers SRAM AXS POD Controller Rear Derailleur SRAM GX Eagle Transmission Derailleur Cassette SRAM GX Eagle Transmission Cassette, 12spd, 10-52t Chain SRAM GX Eagle Transmission Flattop Chain Crankset SRAM GX Eagle Crankset, ISIS interface, Integrated Guard, 55mm Chainline, 155mm Chainrings SRAM 34t T-Type chainring, 104 BCD, steel |
WHEELS & TIRES |
Front Tire Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" Front Wheel Roval Traverse Alloy 29", DT Swiss 370, 15x110mm, 28h Rear Tire Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3" Rear Wheel Roval Traverse Alloy 27.5", DT Swiss 370 XD freehub body, 12x148mm, 32h Inner Tubes Standard, Presta valve |
| COCKPIT | Stem Alloy Trail Stem, 35mm bar bore Handlebars Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S2: 780mm, S3-S5: 800mm Grips Deity Lockjaw grips Saddle Bridge Comp, Hollow Cr-mo rails SeatPost PNW Loam post w/travel adjust S2: 125mm, S3: 170mm, S4/S5/S6: 200mm |
| WEIGHT | 24.41 kg (53 lb, 13.0 oz) |
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
