Technical Specifications
EBIKE |
All New Specialized 3.1 Motor, 101Nm torque, 666W power Battery 840wh battery UI/Remote All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized app Charger Specialized 4amp charger |
|---|---|
FRAMESET |
All new Levo 4 frame, FACT 11m carbon chassis and rear-end, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, w/ SWAT storage, 150mm of travel, side entry battery, fork travel up to 180mm Seat Binder Alloy, 38.6mm |
SUSPENSION |
FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment Fork FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm axle, 44mm offset, 160mm of travel |
BRAKES |
Front Brake SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm Rotor Rear Brake SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Rotor |
DRIVETRAIN |
Shift Levers SRAM AXS POD Controller Rear Derailleur SRAM S1000 Eagle Transmission Derailleur Cassette SRAM 1270 Transmission Cassette, 12 Spd,10-52t Chain SRAM GX Eagle Transmission Flattop Chain Crankset SRAM S1000 Crankset, ISIS interface, Integrated Guard, 55mm Chainline, 155mm Chainrings SRAM T-type ring, 34T, 104 BCD, steel |
WHEELS & TIRES |
Specialized 29F/27.5R, hookless alloy, 30mm inner width, tubeless ready Front Hub Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h Rear Hub Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h Spokes DT Swiss Industry Front Tire Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" Rear Tire Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3" Inner Tubes Standard, Presta valve |
| COCKPIT | Stem Alloy Trail Stem, 35mm bar bore Handlebars Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S2: 30mm rise, 780mm width, S3-S5: 40mm rise 800mm width Grips Specialized Trail Grips Saddle Bridge Comp, Hollow Cr-mo rails SeatPost Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm |
| WEIGHT | 24.41 kg (53 lb, 13.0 oz) |
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
