Specifications
One Bike to Rule All Trails
Capability, Control, Personalization
The all-new Stumpjumper 15 EVO obliterates every trade-off in the trail game. It’s the ‘Bike of the Year’ winning Stumpy 15 you know, turned up to 11—with a longer-travel 160mm FOX fork, external reservoir FOX FLOAT X shock, and a slacker headtube for next-level capability. Devour bumps like a big bike? Check. Short-travel control, playfulness, and efficiency? Double check. A heaping helping of personalization to make it perfect for the only rider who matters—you? Check, check, check.
Frameset
M5 alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
Suspension
Front: 160mm FOX FLOAT 36 Rhythm GRIP
Rear: 145mm FOX FLOAT X GENIE Performance
Front Brake
SRAM DB8 Stealth, 4-piston caliper, hydraulic disc, 200mm rotor
Rear Brake
SRAM DB8 Stealth, 4-piston caliper, hydraulic disc, 200mm rotor
Shift Levers
SRAM Eagle 70
Rear Derailleur
SRAM Eagle 70 Transmission, 12-speed, easy shift under load
Cassette
SRAM 12-speed,10-52t
Chain
SRAM 70 Transmission 12-Speed Flattop Chain
Crankset
SRAM Eagle 70, 165/170mm, 55mm chainline, 32T
Bottom Bracket
SRAM DUB Threaded Wide
Rims
Specialized, hookless alloy, 30mm inner width, tubeless ready
Front Hub
Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 32h
Rear Hub
Specialized alloy rear hub disc, sealed cartridge bearings, 6-Bolt, 12X148mm thru-axle, 32h, HG Steel Fhb
Spokes
DT Swiss Elemental
Front Tire
Butcher, GRID TRAIL casing, Gripton T9 compound, 29X2.4
Rear Tire
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, TLR, S1-S2: 27.5x2.4, S3- S6: 29x2.4"
Inner Tubes
Standard, Presta Valve
Stem
Alloy Trail Stem, 35mm bar bore
Handlebars
Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S6: 800 width, 50mm rise
Grips
Specialized Trail Grips
Saddle
Bridge Comp, Hollow Cr-mo rails 155/143
Seat Post
Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm
Weight
36 lb, 12.7 oz
