Technical Specifications
| Frame | ||
|---|---|---|
|
Material |
Carbon CC | |
|
Features |
- | |
|
Frame |
Carbon CC Gravel | |
|
Travel |
- | |
|
Weight |
30.91lbs / 14.02kg | |
|
Wheel Size |
700c | |
| Suspension | ||
|
Fork |
Carbon | |
|
Shock |
N/A | |
|
Remote |
- | |
| Drivetrain | ||
|
Bottom Bracket |
N/A | |
|
Cassette |
SRAM XG1275 Eagle, 12spd, 10-50t | |
|
Chain |
SRAM SX Eagle, 12spd | |
|
Chainguide |
N/A | |
|
Crank Length |
- | |
|
Crankset |
Praxis eTor AL, 107BCD S: 165mm, M/L: 170mm, XL/XXL: 172.mm | |
|
Front Derailleur |
- | |
|
Left Shifter |
- | |
|
Rear Derailleur |
SRAM Apex Eagle, 12spd | |
|
Right Shifter |
SRAM NX Eagle, 12spd | |
|
Shifters |
- | |
| Brakes | ||
|
Brakes |
SRAM S300 | |
|
Front Brakes |
- | |
|
Front Rotor |
SRAM Centerline, Centerlock, 160mm | |
|
Rear Brakes |
- | |
|
Rear Rotor |
SRAM Centerline, Centerlock, 160mm | |
|
Rotors |
- | |
| Cockpit | ||
|
Bar Width |
- | |
|
Dropper Length |
- | |
|
Grips / Bar Tape |
ESI Chunky Grips | |
|
Handlebars |
RaceFace Ride All Sizes: 35x760mm, 10mm Rise | |
|
Headset |
FSA IS-2/47/42 ACB | |
|
Saddle |
WTB Silverado Medium, CroMo | |
|
Seatpost |
RaceFace Ride, 27.2 All Sizes: 375mm | |
|
Stem |
RaceFace Ride All Sizes: 80mm | |
|
Stem Length |
- | |
| Wheels | ||
|
Front Rim |
WTB ASYM i25 28h 700c | |
|
Front Hub |
WTB Frequency Sport, 12x100, Centerlock, 28h | |
|
Front Tire |
Schwalbe G-One Overland, Pro EVO, 700x50c | |
|
Rear Rim |
WTB ASYM i25 28h 700c | |
|
Rear Hub |
WTB Frequency Sport, 12x148, XD, Centerlock, 28h | |
|
Rear Tire |
Schwalbe G-One Overland, Pro EVO, 700x50c | |
|
Valves |
Reserve Fillmore Valves | |
|
Rims |
- | |
| Ebike | ||
|
Battery |
Fazua 480Wh Integrated Battery | |
|
Drive Unit |
Fazua Ride 60 | |
|
Battery Charger |
Fazua Charger | |
|
Range Extender |
- | |
| Specs | ||
|
Bottom Bracket Shell |
- | |
|
Rear Brake Mount |
Flatmount 160mm Direct | |
|
Chainguide_standard |
- | |
|
Chainline |
- | |
|
Derailleur Hanger |
- | |
|
Shock Length |
- | |
|
Fork Axle to Crown |
430mm | |
|
Fork Compatibility |
- | |
|
Fork Offset |
45mm | |
|
Front Derailleur Mount |
- | |
|
Headset |
IS 41 /IS52 | |
|
Max Chainring Size |
46t | |
|
Max Rotor Size |
180mm | |
|
Max Tire Clearance May vary according to tire and rim model |
50mm | |
|
Front Spacing |
- | |
|
Rear Spacing |
148mm | |
|
Rear Travel |
- | |
|
Recommended Sag |
- | |
|
Sealant |
- | |
|
Seat Clamp Diameter |
- | |
|
Seat Post Diameter |
- | |
|
Shock Bushing Size Front |
- | |
|
Shock Bushing Size Rear |
- | |
|
Shock Mounting Hardware Lower |
- | |
|
Shock Mounting Hardware Upper |
- | |
|
Shock Stroke |
- | |
|
Suspension System |
- | |
|
UDH Compatible |
Yes | |
|
Water Bottle Mounts |
- | |
