BUILT BY RIDERS: Each build starts with a super strong M5 alloy chassis and tough alloy wheels. Stout suspension, powerful brakes, and popular drivetrain options round out these builds to catch big hits, pedal smooth, and provide a ton of stoppage. It’s not for the gram counter—it’s for those riders who push the boundaries of progression and come back for more.
RIDE DYNAMICS TUNED: Before showing up at your doorstep or local bike shop, each STATUS 2 gets a special shock tune from our Specialized Ride Dynamics team—a group that eats, sleeps, and breathes mountain bike suspension. The characteristics of the shock are designed to complement the kinematics of the new STATUS 2 perfectly.
LET’S GET PERSONAL: Each model of STATUS 2 features neatly packaged flip chips (located on the Horst pivot link, close to the rear axle) that allow the rider to finely tune the frame’s geometry to their desired ride or terrain. Bikes ship in the high position but can be ‘flipped’ to lower and slacker—8 mm lower bottom bracket and half a degree slacker head tube angle.
Technical Specifications
FRAMESET |
Frame M5 Alloy chassis and rear-end, Trail Geometry, horst pivot geo adjustment, threaded BB, internal cable routing with external rear brake option, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 170mm of travel Seat Binder Alloy, 38.6mm |
|---|---|
SUSPENSION |
Rear Shock RockShox Vivid, Ride Dynamics Trail Tune, S1:230x60mm, S2-S5:230x62.5mm Fork RockShox Domain Gold RC, Isolater RC damper, three position compression adjustment, 15x110mm axle, 44mm offset, 170mm of travel |
BRAKES |
Front Brake SRAM Maven, 4-piston caliper, hydraulic disc Rear Brake SRAM Maven, 4-piston caliper, hydraulic disc |
DRIVETRAIN |
Shift Levers SRAM EAGLE 70 Rear Derailleur SRAM Eagle 70 T-Type Cassette SRAM 1270 Transmission Cassette, 12 Spd,10-52t Chain SRAM 70 Transmission Chain Crankset SRAM Eagle 70, 55mm chainline, 32T Bottom Bracket SRAM DUB Threaded Wide |
WHEELS & TIRES |
Rims Specialized, hookless alloy, 30mm inner width, tubeless ready Front Hub Specialized alloy front hub disc, sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 28h Rear Hub Specialized alloy rear hub disc, sealed cartridge bearings, 6-Bolt, 12X148mm thru-axle, 28h, HD Steel Fhb Spokes DT Swiss Elemental Front Tire Butcher, GRID TRAIL casing, Gripton T9 compound, 29X2.4 Rear Tire Butcher, GRID GRAVITY Casing, Gripton T9 compound 27.5X2.4 Inner Tubes Standard, Presta Valve |
COCKPIT |
Stem Alloy Trail Stem, 35mm bar bore Handlebars Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S5: 800 width, 50mm rise Grips Deity Lockjaw Grips Saddle Body Geometry Bridge Comp, hollow Cr-Mo rails, 143mm SeatPost X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 125mm, S2: 150mm, S3-S4: 170mm, S5: 190mm |
WEIGHT |
Weight 17.35 kg (38 lb, 4.0 oz) |
