Specifications
The result of years of experience and knowledge, creating a flat pedal that performs better and is more durable.
Redesigned Platform Shape
Platform size has increased compared to the F20 pedal (105 x 102mm usable)
Careful consideration has been given to getting the right balance between foot stability and clearance in narrow gaps and ruts
Asymmetric shape designed to give full support to the shoe sole, extending to areas the F20 platform didn't
All New Pin Design
Reverse loading design prevents pins from coming loose and means you have a much better chance of removing them when you want to
Unique hex shape for extra bite
Height adjustable using supplied spacers
Maximum pin height of 6mm
Concave Profile
The dual concave profile helps hold the shoe on the platform and gives a superior planted feeling
Concavity is enhanced by using shorter pins towards the middle of the platform and having no pin locations in the centre of the platform
Pedal Internals
The proven internal layout of the F20 pedal remains for smooth long-term durability
Three cartridge bearings and an IGUS bush
Internal and external sealing prevents any ingress of dirt and debris
Fully serviceable and re-buildable
Revised axle design for improved strength and impact resistance
