Specifications
Top-tier design, performance-focused spec and thoughtfully integrated features across all models deliver beyond expectations. A full 6066 aluminum frame balances durability with weight savings, making it lighter than the previous generation without compromising strength.
Built on an award-winning reputation with even more capability and refinement. The same Fluid you love, with new technology and a lighter frame in a value-driven package that makes progression feel effortless from the get-go. Confidence, control, and composure for every stage of riding.
FRAME
Aluminum Frame, 130mm Travel, UDH| R-Wheel Size Adj | Ride Aligned™
FORK
RockShox Recon RL 140mm, 44mm Offset
REAR SHOCK
DVO Opal, 210x50mm, Std eyelet
Drivetrain
REAR SHIFTER Shimano CUES SL-U6000-10R, 10sp
REAR DERAILLEUR
Shimano CUES RD-U6000, 10sp, GS
CRANKSET
Shimano CUES FC-U6000-1, 30T, CL55, 165mm(S1,S2) - 170mm(S3,S4,S5)
BOTTOM BRACKET
Shimano, BSA 73mm
CASSETTE
Shimano CUES CS-LG300 10sp 11-48T
CHAIN
Shimano LG-500, 10sp
Brakes
FRONT BRAKE
Tektro HD-M535, 4 Piston , Resin Pads
ROTOR
Tektro TR203, 203mm, 2.3mm Thickness, 6-bolt
REAR BRAKE
Tektro HD-M535, 4 Piston , Resin Pads
REAR BRAKE
ROTOR
Tektro TR203, 180mm, 2.3mm Thickness, 6-bolt
BRAKE LEVERS
Tektro HD-M535
Components
HANDLEBAR
Norco 6061 DB Alloy, 800mm, 25mm Rise(S1,S2) - 35mm Rise(S3,S4,S5)
STEM
Norco 6061, 40mm Length, 35mm Clamp
SEATPOST
TranzX YSI34QL , 31.6mm, 125 (S1) -150mm (S2) -170mm (S3) -200mm (S4,S5)
HEADSET
Tapered 1-1/8"- 1.5",(ZS44/28.6 | ZS56/40)
SADDLE
WTB Solano Med, 142x240 mm, Steel Rails
GRIPS
WTB Wavelength, 140mm Length
SEATPOST CLAMP
Norco Alloy Nutted Clamp, 34.9mm ID
Wheels
FRONT HUB
Formula DC-511, 15x110mm Boost, 32h, 6-bolt
REAR HUB
Formula DC-3248,12x148mm Boost, HG, 32h, 6-bolt
RIMS
WTB ST i30 TCS 2.0 ,30 mm, 32H, 29"
FRONT TIRE
Schwalbe Magic Mary, Trail casing, Ultra Soft , Radial, 29x2.5"
REAR TIRE
Schwalbe Romy, Trail casing, Soft, Radial, 29x2.4"
WEIGHT
16.9 kg (37.2 lbs)
