Technical Specifications
E-BIKE |
Motor All New Specialized 3.1 S-Works motor, 111Nm torque, 720W power Battery 840wh battery UI/Remote All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized app Charger Specialized 12amp smart charger, 4 different charge functions including Standard, Fast, Eco, and charge to 80% |
|---|---|
Frameset |
Frame All new S-Works Levo 4 frame with carbon shock extension, FACT 11m carbon chassis and rear-end, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, w/ SWAT storage, 150mm of travel, side entry battery, fork travel up to 180mm Seat Binder Alloy, 38.6mm |
Suspension |
Rear Shock FOX FLOAT X Factory with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment, 210x55mm Fork FOX FLOAT 38 Factory, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm axle, 44mm offset, 160mm of travel |
BRAKES |
Front Brake SRAM Maven Ultimate, 4-piston caliper, hydraulic disc, 220mm HS2 Rotor Rear Brake SRAM Maven Ultimate, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor |
DRIVETRAIN |
Shift Levers SRAM AXS POD Ultimate Controller with Discrete clamp Rear Derailleur SRAM XX Eagle Transmission Derailleur Cassette SRAM XX Eagle Transmission Cassette, 12spd, 10-52t Chain SRAM XX EagleTransmission Flattop Chain Crankset SRAM XX Carbon crank, 55mm Chainline, ISIS interface, 160mm Chainrings SRAM 34t T-Type chainring, 104 BCD, steel |
WHEELS & TIRES |
Front Tire Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3" Front Wheel Roval Traverse HD 29", hookless carbon, 30mm inner width, tubeless ready, DT Swiss 240 DEG, 15x110mm, 28h Rear Tire Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3" Rear Wheel Roval Traverse HD 27.5", hookless carbon, 30mm inner width, tubeless ready, DT Swiss 240 DEG, 12x148mm, 32h Inner Tubes Standard, Presta Valve |
COCKPIT |
Stem Industry 9 Mountain stem, 35mm clamp, 40mm length Handlebars RaceFace Era Carbon, riser bar, 5-degree upsweep, 8-degree backsweep, S2:20mm Rise, S3-S6:40mm Rise, 800mm Grips Deity Lockjaw grips Saddle Specialized Power Pro Mirror w/hollow Ti rails SeatPost FOX Transfer NEO Factory, 34.9, S2: 150mm, S3: 175mm, S4-S6: 200mm |
Accessories |
SWAT internal downtube storage |
Weight |
Weight 23.68kg (52 lb, 3.3 oz) Weight Size S4 |
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
